| Producent | NETGEAR |
| Type | Switch |
- Cost effective 100G aggregation and 10G access layer for AV deployments and redundant spine & leaf topologies
- Zero Touch AV over IP with pre-configured L2 Multicast on all models (10G AV encoders and decoders) and SDVoE-ready
- Advanced Layer 3 feature set including IP Multinetting/CIDR, Static, PBR, VRRPv2, OSPFv3, PIM-SM, VxLAN, BGP4, VRF-Lite
- Optimized for ""Spine and Leaf"" redundant AV installations, with or without MLAG between spine switches
- Up to 320 TX / 320 RX (10 Gigabit) nodes all line rate with each other in a redundant spine and leaf architecture
The trend of moving matrix switching into the Ethernet network is inevitable and SDVoE already delivers capabilities far beyond that of a traditional matrix switch. Historically it has been simple to design AV over IP systems of up to 96 I/Os using a single switch using Layer-2 Multicast IGMP. However, larger installations required data center-class 100G Ethernet switches with more complex Layer-3 Multicast Routing techniques, adding complexity and cost to the Ethernet infrastructure.
